SAFETY VALVE VS500 G 1/2F G 3/8F 500BAR 80 LPM - 60.5200.00
€222.60
In stock
SKU
60.5200.00
SAFETY VALVE VS500 G 1/2F G 3/8F 500BAR 80 LPM
| SKU | 60.5200.00 |
|---|---|
| Manufacturer SKU | 60.5200.00 |
| Thread tipe | F |
| Thread | 1/2" |
| Connections | IN G1/2" F |
| Bypass | G 3/8" F |
| Rated Pressure | 500 BAR - 50 MPa - 7250 psi |
| Rated Flow Rate | 80 l/min - 21 USGpm |
| Rated Temperature | 90 °C - 195 °F |
| Pressure type category | High pressure |
| Material | Brass |
| Plastic knob (P.Regulators) | No |
| Manufacturer/Brand | P.A. Italy |
| Made in | Italy |
SAFETY VALVE VS500 G 1/2F G 3/8F 500BAR 80 LPM
Compensated pressure regulating valve.
Regulates the bypass of the fluid with a minimum variation of the pressure. Suitable to be utilized as a relief valve in pressure washers.
The valve has been designed for a continuous use at a water temperature of 60°C. It can resist for short periods at a maximum
temperature of 90°C.
Key features:
- Central body and fittings in brass.
- Internal components in Stainless Steel.
- Moving parts totally protected.
AS A RELIEF VALVE IN PRESSURE WASHERS:
- Secure intervention discharging all the flow.
- Prompt and effective damping against pressure spikes.
