SAFETY VALVE MG1000 G1/4" M - HOSE BARB 6 mm - 00033001 - 1120030100
€17.80
In stock
SKU
00033001
SAFETY VALVE MG1000 G1/4" M - HOSE BARB 6 mm 220 BAR 30 LPM
| SKU | 00033001 |
|---|---|
| Manufacturer SKU | 1120030100 |
| Thread tipe | M |
| Thread | 1/4" |
| Connections | IN G1/4"M |
| Bypass | Hose Barb Ø 6 mm - 0.24” |
| Rated Pressure | 220 BAR - 22 MPa - 3200 psi |
| Rated Flow Rate | 30 l/min - 8 USGpm |
| Rated Temperature | 90 °C - 195 °F |
| Pressure type category | High pressure |
| Material | Brass |
| Plastic knob (P.Regulators) | No |
| Manufacturer/Brand | MTM |
| Made in | Italy |
SAFETY VALVE MG1000 G1/4" M - HOSE BARB 6 mm 220 BAR 30 LPM
Compensated pressure regulating valve.
Regulates the bypass of the fluid with a minimum variation of the pressure. Suitable to be utilized as a relief valve on pressure washers.
The valve has been designed for a continuous use at a water temperature of 60°C. It can resist for short periods at a maximum
temperature of 90°C.
- Rated pressure: 220 BAR 22 MPa 3190 PSI
- Permissible pressure: 250 BAR 25 MPa 3625 PSI
- Central body in brass
- Internal components in SS.
- Moving parts totally protected.
- Discharge through integrated hose barb.
- Secure intervention discharging all the flow.
